TD series belt drive side-entry Agitator mixer

FOB Reference Price:Get Latest Price
US $500-1,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
AAA
Model Number:
TD
Colour:
Green (factory standard)
Motor Power:
0.55 ~ 30 KW
Output Speed:
200 ~ 600 RPM
Wetted Part Material:
According to Design Requirement
Seal Type:
Mechanical Seal
SupplyAbility
SupplyAbility:
1 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden Case
Port
CHINA PORT
Lead Time :
30DAYS

TD series belt drive side-entry mixers

Product Feature:
TD series side-entry mxiers use synchronize tooth belt, so the structure is compact and the tranmission efficency is high. With inner pedestal structure, this mixer is suitable for such conditions as fluid without solids, or long extended shaft. The shut-off device at the head of the pedestal permit the maintenance of the sela or reducer without discharge the tank fluid.



Selection table for TD mixers

n

(r/min)

Output Speed

200

240

300

370

470

600

i Reduction Ratio

5

4

5

4

3.15

2.5

P

(kW)

Motor Power

6  6-pole Motor

4 4-pole Motor

0.55













0.75













1.1







TD1





1.5













2.2













3.0













4.0





TD2







5.5













7.5













11













15













18.5





TD3







22

×











30

×

×

×







NOTE

TD,0.557.5kW,1130kW.

The mixer of 0.557.5kW is hanged by rope and 1130kW is foot-mounted type.





Guarantee :

This warranty period is (12) months after first installation of mixers or (18) months after its shipment from our factory, whichever occurs first.



After Sales Service

 GREATWALL has an excellent service team including first-class mixing technology experts, professionally mechanical engineers and highly experienced technicians. We can support you to install your mixers properly and get the optimal performance.



Payment terms:

 1.30% Down Payment by T/T after PO and 70% Balance Payment by T/T Prior Shipment.

2. 100% Irrevocable L/C at Sight.



Packing:

  1. 1.    Exporting Standard Packing,



Shipment terms:

  1. 1.     Shipping Method:  By Sea/By Air/ By Courier
  2. 2.     Term of Shipment : EXW, FOB, CIF, FCA.CFR,DDU

customer
